Stirring & Mixing

Crossover 1540

Powerful industrial mixer.

Description Features Configuration Application

Mixing up to 200 litres (55 gallons) of basic pre-mix, industrial pilot plant volumes, or full production batches, this portable mixer weighs only 12 kg (26.5 lb).

Operate while wearing PPE or sterility gloves
Precisely set desired speed or adjust on screen
Meet the changing needs of multiple facilities
Easy installation to North American grounded outlet
Improve mixing and impeller functionality
Assign an identifier name or number to each mixer
Optional auto-start operation upon power restoration
Monitor viscosity changes as they relate to torque
Set total mixing time; stop mixing or sound alarm
Track total mixing time from power up
Stop mixing or sound alarm at desired torque reading
Notification of desired time or torque level
Integrate into existing monitoring and control systems
Capability for RS232 RS485 PLC and Ethernet or PC
Document results: speed / torque / time / date
Protection in aggressive environments; wash down
Easily access button to immediately stop mixing
Protects display; replaceable if covered by splashes or dust
Guard spinning chuck and upper shaft for safety
Holds shaft securely; diameters up to 16 mm (?')
Shift gears without manually stopping mixer
High efficiency no maintenance motor
Always available – no required maintenance schedule

- Intuitive Speed Adjustment
- Resistive Touch Screen Display
- Portable
- 120 V cord set
- Counter-clockwise rotation selection
- Name Customization
- Resume on Power up
- Torque Zero feature
- Cycle Timer
- Run Time Display
- Torque Min/Max Setting
- Audible Alarm
- PC/PLC connectivity
- Multiple com ports
- Data Logging
- Sealed Housing
- Quick Stop
- Installed Screen Protector
- Chuck Shaft Guard
- Adjustable Keyed Chuck
- Automatic Transmission
- Brushless DC motor - fan cooled
- Maintenance Free

Key Specifications:

Speed Range ● 50-1500 rpm, (0.83 - 25 hertz)

Max Torque ● 3000 Ncm

Max Viscosity ● 180,000 cP

Output Power ● 1/2 hp, 300 watts

Max Volume ● 200 litres

The Caframo 1540 combines industrial control features and incredible amounts of power creating a portable mixer perfectly suited for lab or production batches. Resume on power up allows precise control by a PC or PLC. Plug in a USB drive for immediate data logging of date, speed, time and torque. Alarms, timers, PC programmability as well as “mount and plug in” installation provide a transportable mixer from bench top to barrel.
